TECTYL 5655 is a wax based, solvent type, cold applied, corrosion preventative designed for use on ferrous and non-ferrous metals when exposed to indoor or outdoor storage conditions. TECTYL 5655 deposits an amber, transparent, firm, wax-like film that is readily removable by conventionally used solvents or degreasing methods. TECTYL 5655 is formulated to fulfill the requirements of MIL-PRF-16173E, Grade #4, Class I Military specification.

SUGGESTED USES

Overseas shipments of unpainted metal parts and engine housings, indoor or outdoor, with or without cover.

Indoor protection of machinery, equipment, automotive body panels and tools.

Long-term, general-purpose protection of metal parts, dies, tools, and rolls, where a removable film is needed.

APPLICATION

TECTYL 5655 can be applied by dipping, brushing, or spraying. When dipped, the wet applied film thickness ranges from 3.0 to 5.0 and will dry in 1 hour to a film thickness of 1.5 to 2.5 mils. Under these conditions, TECTYL 5655 coverage is 530 to 320 sq/ft per gallon. TECTYL 5655 cures by solvents evaporation. Adequate ventilation is required for cure and to prevent the formation of an explosive atmosphere. Further information is provided in the SDS sheet.

PHYSICAL PROPERTIES  (Typical Values, Not Specifications)

Appearance:                                    Amber, translucent viscous liquid

Film Type:                                        Non-tacky (dries completely), amber, wax-like, transparent film.

Percent non-volatiles:                      52.5% by Weight

Flash Point:                                      105^oF. (Min.)

Pounds per Gallon:                           7.21 lbs/gal @ 77^oF

Volatile Organic Content (VOC):       3.45 lbs./gal

Viscosity, Zahn EZ #5:                      52 Seconds @ 77^oF.

PROTECTIVE PROPERTIES    (Typical Values)

Low Temperature Flexibility (-10^oF):        Pass No Cracking or loss of adhesion
90^o Mandrel Bend

Outdoor Exposure (Uncovered):              2 Year (Min.)

Shed Exposure:                                       5 Years (Min.)

Salt Spray (ASTM-B-117):                       336 Hours (Min.)

Humidity Cabinets:
(ASTM-D-1748)                                       1500 Hours (Min.)

SURFACE PREPARATION

The maximum performance of TECTYL 5655 can be achieved only when the metal surfaces to be protected are clean, dry, and free of rust, oil, and mill scale.

REMOVAL

TECTYL 5655 can be removed by using mineral spirits, kerosene, or citrus base solvents. This product can also be removed by vapor degreasing.

STORAGE

Store TECTYL 5655 at temperatures between 50-95°F (10-35°C). Mild agitation is recommended prior to use as settling can occur.

CAUTION

Adequate ventilation is required for cure and to ensure against formation of a combustible liquid. THE PARTIALLY CURED FILM SHOULD NOT BE EXPOSED TO IGNITION SOURCES SUCH AS FLARES, FLAMES, SPARKS, EXCESSIVE HEAT, OR TORCHES. Refer to Daubert’s Material Safety Data Sheet for additional handling and first aid information.
